1. Male Thread Socket
Non-Valved | Thread Size | Length | Width | Height |
50GP-S1-04 | 1/4"NPT | 1.40" | 0.75" | 0.93" |
2. In-Line Hose Barb Socket, Short Body
Non-Valved | Tube Size | Metric Tube | Length | Width | Height |
50GP-S5-04 | 1/4" ID | 6.4mm ID | 1.35" | 0.75" | 0.93" |
50GP-S5-06 | 3/8" ID | 9.5mm ID | 1.35" | 0.75" | 0.93" |
3. In-Line Hose Barb Socket, Long Body
Non-Valved | Valved | Tube Size | Metric Tube | Length | Width | Height |
50GP-S5-06LB | 50GPV-SF5-06 | 3/8" ID | 9.5mm ID | 2.00" | 0.83" | 0.94" |
4. Elbow Hose Barb Socket
Non-Valved | Tube Size | Metric Tube | Length | Width | Height |
50GP-S7-06 | 3/8" ID | 9.5mm ID | 1.23" | 0.75" | 1.50" |
1. Male Thread Plug
Non-Valved | Thread Size | Length | Width | Height |
50GP-PF1-04 | 1/4"NPT | 1.35" | 0.62" | 0.62" |
2. In-Line Hose Barb Plug
Non-Valved | Tube Size | Metric Tube | Length | Width | Height |
50GP-PF5-04 | 1/4" ID | 6.4mm ID | 1.35" | 0.62" | 0.62" |
50GP-PF5-06 | 3/8" ID | 9.5mm ID | 1.35" | 0.62" | 0.62" |
3. Elbow Hose Barb Plug
Non-Valved | Tube Size | Metric Tube | Length | Width | Height |
50GP-PF7-06 | 3/8" ID | 9.5mm ID | 1.25" | 0.62" | 1.26" |
4. End Stop Plug
Non-Valved | Length | Width | Height |
50GP-PF6 | 1.20" | 0.69" | 0.69" |
