JACO Features and Materials 피팅 주문 방법 10 Male Connector 15 Union & Reducing Union Connectors 20 Bulkhead Unions 25 Female Connectors 40 Male Elbows 45 Female Elbows 50 Union & Reducing Elbows 60 Male Branch Tees 70 Union & Reducing Tees 75 Male Run Tees P PN BLD CV B

Union Tees

Tube
O.D.

Pipe
Thd.

Thread

A
±1/64

B
±1/64

D
+.005/-.010

E

F
±1/64

G
±1/64

H
±1/64

K
±1/64

L
±1/64

M
±1/64

Part
No.

1/4"

1/8"

7/16-20

1-29/64

47/64

1/4"

.330 - .335

.170

15/32

3/4

3/8

1/4

3/8

60-4-2

1/4"

1/4"

7/16-20

1-15/32

47/64

1/4"

.330 - .335

.170

15/32

59/64

3/8

5/16

3/8

60-4-4

5/16"

1/4"

1/2-20

1-39/64

13/16

5/16"

.380 - .385

.232

31/64

63/64

7/16

9/32

7/16

60-5-4

3/8"

1/4"

5/8-20

1-15/16

31/32

3/8"

.460 - .465

.250

19/32

1-1/16

9/16

5/16

9/16

60-6-4

3/8"

3/8"

5/8-20

1-29/32

61/64

3/8"

.460 - .465

.250

19/32

1-3/32

1/2

3/8

1/2

60-6-6

1/2"

3/8"

3/4-20

2-13/64

1-7/64

1/2"

.590 - .595

.375

11/16

1-5/32

43/64

25/64

43/64

60-8-6

1/2"

1/2"

3/4-20

2-7/32

1-1/8

1/2"

.590 - .595

.375

11/16

1-21/64

5/8

31/64

39/64

60-8-8

5/8"

1/2"

7/8-20

2-17/32

1-1/4

5/8"

.715 - .720

.500

45/64

1-7/16

13/16

1/2

13/16

06-10-8

3/4"

1/2"

1-1/16-20

3-7/64

1-9/16

3/4"

.860 - .865

.625

13/16

1-41/64

1-1/16

9/16

1-1/16

60-12-8

3/4"

3/4"

1-1/16-20

3-7/64

1-9/16

3/4"

.860 - .965

.625

13/16

1-41/64

1-1/16

11/16

1-1/16

60-12-12

7/8"

3/4"

1-3/16-16

3-3/32

1-35/64

7/8"

.995 - 1.000

.750

7/8

1-5/8

1-3/16

11/16

1-3/16

60-14-12

Reducing Tees

Tube O.D.	Thread	A ±1/64	B ±1/64	D +.005/-.010	E	F ±1/64	G ±1/64	JACO No.
Tube O.D.	Thread	A ±1/64	B ±1/64	D +.005/-.010	E	F ±1/64	G ±1/64	JACO No.
5/8 - 3/8	7/8-20 - 5/8-20	2-17/32	1-17/64	5/8"	.715 - .720	.500	45/64	70-10-6
7/8 - 5/8	1-3/16-16 - 7/8-20	3-3/32	1-35/64	7/8"	.995 - 1.000	.750	7/8	70-14-10
7/8 - 5/8	1-3/16-16 - 7/8-20	3-1/64	1-29/64	7/8"	.995 - 1.000	.500	7/8	70-14-10-10
