• 다양한 유량 범위를 위해 카트리지에는 여러 튜브 사이즈를 사용할 수 있습니다.

• 튜브 교체를 위해 카트리지를 넣다 뺐다할 수 있으며, 다른 채널의 튜브의 펌프 작업을 방해하지 않으면서 하나의 튜브만 교체할 수 있습니다.

• 정확성을 높이기 위해 occlusion의 보정을 정밀하게 할 수 있습니다.

• 하나의 카트리지만 사용할 수도 있고, 최대치를 사용할 수도 있습니다.

• 디지털 Dispensing 드라이브는 유지보수가 필요 없는 brushless 모터를 사용합니다.

• 자동화 Dispensing 작업을 위해 지연 간격을 포함한 Dispensing 기준을 설정할 수 있습니다.

• 4 채널, 8개의 롤러를 포함한 펌프는 더 나은 정확성을 갖기 위해 최저 Pulsation을 제공합니다.

• 1/10-hp, 지속 작업이 가능한 brushless 드라이브

• ±0.1% 드라이브 속도 조정을 위한 타코 피드백

• 드라이브의 DB25 Female 커넥터를 통한 원격 조정

• IP33 등급의 겹침이 가능한 ABS 하우징

• 잠금 기능의 Membrane 키패드

사양 및 주문 정보

Part No.	Flow range (mL/min)	Pump head included	Tubing included	Tubing size accepted	Drive included	Drive Speed range	Drive IP rating	Power (50/60Hz)

L/S 8-channel 4-roller cartridge pump system
77919-20	0.0034 to 18	L/S Cartridge head 07519-06 with 8-small cartridges 07519-20	PVC microbore tube set, 1.42mm ID 06416-34; pk of 12	Microbore tube sets; L/S 13, L/S 14	07523-90	0.02 to 100	IP33	90~130, 2.2A 190 ~260, 1.1A




L/S 맥동을 줄인 4채널 8 롤러 카트리지 펌프 시스템
77919-30	0.0024 to 12	L/S Cartridge head 07519-20 with 4 small cartridges 07519-85	PVC microbore tube set, 1.42mm ID 06416-34; pk of 12	Microbore tube sets; L/S 13, L/S 14	07523-90	0.02 to 100	IP33	90~130, 2.2A 190 ~260, 1.1A
